Product Details
Place of Origin: China
Brand Name: OEM
Certification: IATF16949:2016
Model Number: 7006C-2RZ Precision Angular Contact Ball Bearing
Payment & Shipping Terms
Minimum Order Quantity: 100
Price: Please contact us
Packaging Details: plastic bag,box,carton,pallet
Delivery Time: 30 days
Supply Ability: 500000pcs per month
Part Number: |
7006C-2RZ Precision Angular Contact Ball Bearings |
Tolerance Class: |
P4 |
Seals Color: |
Red And Black |
Contact Angle: |
15° C Angle |
Lubrication: |
Grease |
Preload: |
Light |
Interchangeable With: |
SKF |
Sealed Type: |
2RZ |
Part Number: |
7006C-2RZ Precision Angular Contact Ball Bearings |
Tolerance Class: |
P4 |
Seals Color: |
Red And Black |
Contact Angle: |
15° C Angle |
Lubrication: |
Grease |
Preload: |
Light |
Interchangeable With: |
SKF |
Sealed Type: |
2RZ |
7006C-2RZ Precision Angular Contact Ball Bearings 30x55x13mm Sealed Spindle Tools
Design Features of the 7006C-2RZ Precision Angular Contact Bearing
The 7006C-2RZ Precision Angular Contact Ball Bearing is crafted from superior materials and manufactured to exacting standards. It’s perfectly suited for high-speed spindles and precision instruments where accuracy and rapid operation are essential. This bearing delivers outstanding performance and maintains reliability even under challenging conditions.
|
Bearing Number |
Dimensions(mm) |
Basic Load Rating(N) |
Limiting Speed(rpm) |
Weight(Kg) |
||||||
|
Inner Diameter |
Outer Diameter |
Width |
Chamfer |
Dynamic |
Static |
Grease |
Oil |
|||
|
d |
D |
B |
rsmin |
r1smin |
Cr |
Cor |
Non-contact |
Non-contact |
reference |
|
|
7006C-2RZ |
30 |
55 |
13 |
1 |
0.6 |
14500 |
9850 |
9500 |
/ |
0.11 |
|
Ring Material |
Steel |
|
Roller Material |
Steel Ball,Ceramic available |
|
Cage Material |
Bakelite Phenolic |
|
Contact Angle |
15°,25° & 40° available |
|
Lubrication |
Required Grease |
|
Matched Arrangement |
Available |
|
Preload |
Available |
|
Number Of Bearings In Matched Set |
2 pcs/set |
|
Universal Matching Bearing |
Yes,DB,DF,DT(Back to Back,Face to Face,Tandem) |
|
Temperature Range |
-30°C ~ +110°C |
|
ABEC Rating Precision |
P4 (ABEC7)P5,P2 available |
|
CERTIFICATE |
RoHS, IATF16949:2016 |
|
For Load Direction |
Angular Contact |
|
Service |
OEM&ODM Customized Services |
|
Samples |
Please Contact Us |
|
Service |
Online Support,Professional Service |
|
Size |
Standard,For custom sizes ,please contact us |
|
Factory Manufacturer |
Yes |
7006C-2RZ Precision Angular Contact Ball Bearing Key Design Features:
Dimensions:
Bore Diameter: 30 mm
Outer Diameter: 55 mm
Width: 13 mm
Material Quality: Crafted from high-quality materials to ensure durability and reliability under demanding conditions.
Precision Manufacturing: Manufactured to extremely tight tolerances, ensuring superior dimensional and geometric accuracy.
High-Speed Capability: Optimized for high-speed operation with minimal heat generation and friction, making it ideal for applications requiring rapid rotation.
Load Capacity: Capable of handling both radial and axial loads efficiently, thanks to its angular contact design.
Preload Options: Available with various preload options to enhance stiffness and reduce play, improving overall system precision.
Surface Finish: Superior surface finish on raceways and rolling elements reduces noise and extends service life.
This bearing is an essential component in industries that demand high precision and performance, such as machine tool spindles,high-speed machinery,aerospace components,medical equipment,semiconductor manufacturing,automotive industry,and scientific instruments.
What are the applications of 7006C-2RZ Precision Angular Contact Ball Bearing?
Aerospace
Aircraft Landing Gear, Gyroscopes: Equipment that requires high precision and reliability.
Machine Tools
Spindles, Feed Systems: Components that demand high precision and stability.
Industrial Automation
Robot Joints, Servo Motors: Transmission systems requiring high precision and reliability.
Medical Equipment
High-Speed Dental Tools, Surgical Instruments, Imaging Devices: Applications with stringent requirements for cleanliness and reliability.
Automotive Components
Generators, Air Conditioning Compressors, Steering Systems: Rotating parts of vehicle auxiliary systems.
Precision Instruments
Measuring Instruments, Laboratory Equipment: Occasions where precision is strictly required.
Wind Power Equipment
Generators, Yaw Systems: Components needing high reliability and long service life.
