Deep Groove Ball Bearing 6001 2RS C0 12x28x8 Bearing Single Row

Product Details

Place of Origin: China

Brand Name: CNBTZC or OEM

Certification: IATF16949:2016

Model Number: 6001 2RS

Payment & Shipping Terms

Minimum Order Quantity: 100000

Price: Please contact us

Packaging Details: plastic tub,carton,pallet

Delivery Time: 30 days

Supply Ability: 1 million pcs per month

Get Best Price
Highlight:

Deep Groove Ball Bearing 6001 2RS

,

6001 2RS Bearing

,

12x28x8 Bearing

Part Number:
6001 2RS C0 Deep Groove Ball Bearings
Type:
Ball Bearing
Structure:
Deep Groove
Number Of Row:
Single Row
Vibration:
Z3, Z4
Noise:
V3, V4
Precision:
P6
Clearance:
C0,C2,C3,C4,EM
Part Number:
6001 2RS C0 Deep Groove Ball Bearings
Type:
Ball Bearing
Structure:
Deep Groove
Number Of Row:
Single Row
Vibration:
Z3, Z4
Noise:
V3, V4
Precision:
P6
Clearance:
C0,C2,C3,C4,EM
Deep Groove Ball Bearing 6001 2RS C0 12x28x8 Bearing Single Row

6001 2RS C0 Deep Groove Ball Bearings Single Row 12*28*8mm Aluminum Saws



The 6001 2RS bearing is a widely used deep groove ball bearing, known for its simplicity, reliability, and versatility. Here’s a detailed introduction to this popular bearing type:

Bearing Number Dimensions(mm) Basic Load Rating(N) Limiting Speed(rpm) Weight(Kg)
Inner Diameter Outer Diameter Width Chamfer Dynamic Static Grease Oil
d D B r(min) Cr Cor Non-contact Non-contact Reference
6001 2RS 12 28 8 0.3 5100 2370 18000 / 0.022



Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Nylon/Steel
Lubrication Grease
Measurement Unit Metric
Seal Type ZZ(2RS,2RZ, open types are available)
Temperature Range -40°C ~ +180°C
CERTIFICATE RoHS, IATF16949:2016
Feature Long Life,Low Noise,High Speed
Service OEM&ODM Customized Services
Samples Please Contact Us
Service Online Support,Professional Service
Size Standard,For custom sizes ,please contact us
Factory Manufacturer Yes
Size Standard,For custom sizes ,please contact us
Bearing Type Ball
For Load Direction Radial
Construction Single Row
Tolerance Class P6
Radial Clearance C0



Requirements for Bearings in Aluminum Saws

An aluminum saw typically uses four sets of bearings with the following requirements:

  1. High Speed Operation: The bearings must support speeds of 5,000 RPM or higher.
  2. No Oil Leakage: The bearings must prevent oil leakage during high-speed operation.
  3. Excellent Dust Protection: They should effectively block external dust from entering the bearing interior.
  4. High Impact Load Resistance: The bearings need to withstand significant impact loads.



Deep Groove Ball Bearing 6001 2RS C0 12x28x8 Bearing Single Row 0



Deep Groove Ball Bearing 6001 2RS C0 12x28x8 Bearing Single Row 1

Deep Groove Ball Bearing 6001 2RS C0 12x28x8 Bearing Single Row 2Deep Groove Ball Bearing 6001 2RS C0 12x28x8 Bearing Single Row 3

What's the Performance Features of 6001 2RS Bearings in Aluminum Saw?



The 6001 2RS bearing is ideally suited for aluminum saws, offering high-speed operation at 5,000 RPM or higher, effective prevention of oil leakage through its double rubber seals (2RS), excellent dust protection to block contaminants, and robust resistance to high impact loads. This makes it a reliable choice for the demanding conditions encountered in aluminum cutting applications.



What's the Applications of the 6001 2RS Bearing?



The 6001 2RS bearing, a deep groove ball bearing with rubber seals, is widely used across multiple industries for its reliable performance and versatility. In the automotive industry, it supports components like generators and electric propulsion systems, handling high speeds and moderate loads while preventing lubricant leakage. In machinery equipment, it ensures smooth operation in devices such as grinders, plastic pipe machines, magnetic separators, and blow molding machines. For home appliances like refrigerators and washing machines, it maintains stable performance in varying temperature conditions. In electronic devices, its low-noise and high-speed capabilities make it ideal for motors and instrumentation. In industrial automation, it withstands complex loads in CNC machines and robotics, ensuring precise movements. Additionally, it finds application in specialized areas like aluminum welders, condensers, sewing machine parts, and medical devices. Overall, the 6001 2RS bearing's durability and broad applicability make it essential in numerous industrial and consumer applications.

If you have more specific questions about the 6001 2RS bearing or need additional information, feel free to ask!
